デジタル庁 (Digital Agency Japan)
「誰一人取り残されない、人に優しいデジタル化を」をミッションとする日本のデジタル庁公式デザインシステム (DADS) v2.13.0。WCAG 2.2 AA / JIS X 8341-3:2016 準拠の政府向け UI 言語で、Noto Sans JP 単一フォントスタックと 13 段階のブルースケール (#e8f1fe → #000060) を基盤に、装飾より情報階層を重視したクリーンでミニマルなレイアウトを定義。最小タッチターゲット 44px、テキストコントラスト 4.5:1 以上、色覚多様性 (C/P/D 型) 検証済みなど、アクセシビリティ制約を設計レベルで組み込んでいる。デザインデータは Figma Community で公開、実装は Tailwind CSS プラグイン + React / 素の HTML コンポーネントの両形態で提供。日英バイリンガル対応。

Color Palette
Primary Action (推定)
Blue Scale (13 Levels)
Neutrals (SolidGray 12 Levels)
Semantic Status
Logo
Typography
Fonts
Noto Sans JP
primary'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif
本文・見出し・UI 全般。SIL Open Font License 1.1。日英混在コンテンツに最適化、中間ウェイト (500/600) は使用しない設計判断
Noto Sans Mono
mono'Noto Sans Mono', monospace
コードブロック・等幅表示用 (14px〜24px の 6 スタイル)
Type Scale
他 1 件を省略
日本語タイポグラフィ
禁則処理・行間・字間・OpenType 機能の設定
- フォントスタック
'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif- 行間
- 1.75(欧文 1.43 に対し約 22% 広い)
- 字間
- 0
- 禁則処理
word-break: keep-allline-break: strict- OpenType
- palt(プロポーショナル仮名): offkern: on
「日本語タイポグラフィの再現」
私たちは、文字の美しさと読みやすさを両立させるデザインを追求しています。 Webフォントは表示速度に影響しますが、適切な行間(line-height)と字間 (letter-spacing)を設定することで、可読性が向上します。 禁則処理を適用することで、行末に句読点や括弧が来るのを防ぎます。
※ Noto Sans JP の単一スタック (他フォントへの切り替えは Don't 違反)ウェイトは 400 / 700 のみ運用、500 / 600 は使用しない本文 line-height は 1.75 (175%) を採用、日本語の可読性を優先ボタン・UI ラベルには Oneline (line-height: 1.0) を使う
Spacing
ベースユニット: 8px
8pxコンポーネント内最小パディング16px標準的な要素間隔24pxセクション内グループ間隔32px中間スペース・ガター幅 (本文 16px × 2)40px中余白48pxセクション間64px大セクション区切りShape
Border Radius
sm
4px
md
6px
lg
8px
xl
12px
2xl
16px
3xl
24px
4xl
32px
full
9999px
Components
Button
Filled Button (Primary)
プライマリブルー背景のメイン CTA。重要度高。最小タッチターゲット 44px、ボタンテキストは Oneline スタイル (line-height: 100%)
Outline Button (Secondary)
白背景 + ブルー 1px 枠のセカンダリボタン。重要度中
Text Button (Tertiary)
透明背景 + 下線のテキストボタン。重要度低
Card
Card
単一トピックをグルーピングする白背景コンテナ。サムネイル + 見出し + 本文 + リンク/アクションで構成
input
Text Input
標準テキスト入力。フォーカスでブルーリング、エラーで赤ボーダー
Default
Focus
Error
Disabled
banner
Notification Banner
ステータス通知バナー。Standard (角丸全体) / Color Chip (左側に太いアクセントボーダー) の 2 スタイル。アイコン + テキストで色覚多様性に配慮
Success
Error
Warning Yellow
Warning Orange
Info Blue
Info Black
chip
Chip / Tag
ピル形状のラベル要素。状態表示・カテゴリ分類用
Default
focus
Focus Ring
フォーカス状態の視覚インジケーター。すべてのインタラクティブ要素に必須
Default
Guidelines
Do
- Noto Sans JP のみを使用する — 他フォントへの切り替えは不可
- ブルーを主要インタラクション色として一貫して使用する (Blue-700: #3460fb)
- 本文テキストには Gray-900 (#1a1a1a) を基本にする
- テキストの最低コントラスト比 4.5:1 を維持する (WCAG 2.2 AA)
- 非テキスト要素の最低コントラスト比 3:1 を維持する
- フォーカスインジケーターを必ず視覚的に明示する
- ボタンの最小タッチターゲットを 44px × 44px に保つ
- 8px グリッドでスペースを定義する
- カラーとアイコン/ラベル/パターンの両方で情報を伝える (色覚多様性対応)
- ボタンはページ内の重要度順に Filled → Outline → Text と使い分ける
- ボタンには Oneline スタイル (line-height: 100%) を使う
Don't
- Gray-420 (#949494) より薄いグレーをテキストに使用しない
- Gray-536 (#767676) より薄いグレーをテキストコントラストとして使用しない
- プライマリ (Filled) ボタンを複数並べて重要度を希釈しない
- ロゴを変形・再彩色・トリミングしない (#252020 の単色のみ)
- フォントウェイト 500 / 600 を使用しない (400 と 700 のみ)
- リンクの visited 色 (Magenta/Purple) をナビゲーション要素に転用しない
- カラーのみで情報を伝えない (アイコン・ラベル・パターンを併用する)
- プライマリ青をテキストの大段落色として使わない (リンクとの識別不可)
---
version: "2.13.0"
name: デジタル庁 (Digital Agency Japan)
description: 日本のデジタル庁公式デザインシステム (DADS) — アクセシビリティ優先の政府向けUI言語。Noto Sans JP とブルー主体のトークンパレットで WCAG 2.2 準拠を実現する。
sources:
- https://www.digital.go.jp/
- https://design.digital.go.jp/
- https://design.digital.go.jp/foundations/color/
- https://design.digital.go.jp/foundations/typography/
- https://design.digital.go.jp/foundations/spacing/
- https://design.digital.go.jp/foundations/layout/
- https://design.digital.go.jp/foundations/elevation/
- https://design.digital.go.jp/components/button/
- https://design.digital.go.jp/components/
- https://raw.githubusercontent.com/digital-go-jp/design-tokens/main/figma/tokens.json
notes:
- 全カラー値は digital-go-jp/design-tokens リポジトリの figma/tokens.json から直接抽出。直接証拠。
- セマンティックカラー (primary, link) は Figma で定義されているが CSS 非公開のため、ボタンドキュメントと公式サイト観察から推定。
- ロゴ色 (#252020) は /themes/custom/gov_theme_da_2023/logo.svg の fill 値から直接抽出。
- エレベーション (shadow) の具体的な CSS 値は非公開。8段階の構造のみ文書化。
- ボタンサイズ (px) はコンポーネントドキュメントから直接抽出。
- WCAG 2.2 / JIS X 8341-3:2016 準拠は設計上の制約として明示されている。
colors:
# --- ロゴ ---
logo: "#252020"
# --- ブルー (13段階) ---
blue-100: "#e8f1fe"
blue-200: "#d9e6ff"
blue-300: "#c5d7fb"
blue-400: "#9db7f9"
blue-500: "#7096f8"
blue-600: "#4979f5"
blue-700: "#3460fb"
blue-800: "#264af4"
blue-900: "#0031d8"
blue-1000: "#0017c1"
blue-1100: "#00118f"
blue-1200: "#000071"
blue-1300: "#000060"
# --- ニュートラル ---
white: "#ffffff"
black: "#000000"
gray-50: "#f2f2f2"
gray-100: "#e6e6e6"
gray-200: "#cccccc"
gray-300: "#b3b3b3"
gray-400: "#999999"
gray-420: "#949494"
gray-500: "#7f7f7f"
gray-536: "#767676"
gray-600: "#666666"
gray-700: "#4d4d4d"
gray-800: "#333333"
gray-900: "#1a1a1a"
# --- セマンティック ---
success: "#259d63"
success-dark: "#197a4b"
error: "#ec0000"
error-dark: "#ce0000"
warning-yellow: "#b78f00"
warning-yellow-dark: "#927200"
warning-orange: "#fb5b01"
warning-orange-dark: "#c74700"
typography:
display:
fontFamily: "'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif"
fontSize: "48px–64px"
lineHeight: "140%"
fontWeight: 700
h1:
fontFamily: "'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif"
fontSize: "36px"
lineHeight: "150%"
fontWeight: 700
h2:
fontFamily: "'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif"
fontSize: "32px"
lineHeight: "150%"
fontWeight: 700
body:
fontFamily: "'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif"
fontSize: "16px"
lineHeight: "175%"
fontWeight: 400
label:
fontFamily: "'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif"
fontSize: "16px"
lineHeight: "100%"
fontWeight: 400
mono:
fontFamily: "'Noto Sans Mono', monospace"
fontSize: "14px–24px"
lineHeight: "150%"
fontWeight: 400
rounded:
sm: "4px"
md: "6px"
lg: "8px"
xl: "12px"
2xl: "16px"
3xl: "24px"
4xl: "32px"
full: "9999px"
spacing:
base: "8px"
components:
button-filled:
backgroundColor: "{colors.blue-700}"
color: "{colors.white}"
borderRadius: "{rounded.lg}"
minTouchTarget: "44px"
button-outline:
backgroundColor: "{colors.white}"
color: "{colors.blue-700}"
border: "1px solid {colors.blue-700}"
borderRadius: "{rounded.lg}"
button-text:
backgroundColor: "transparent"
color: "{colors.blue-700}"
textDecoration: "underline"
---
## Overview
デジタル庁デザインシステム (DADS) は、日本の政府・公共機関向けウェブサイトおよびアプリケーションのための公式デザイン言語。バージョン 2.13.0 (2024年5月30日 β版公開)。
**ミッション:** 「誰一人取り残されない、人に優しいデジタル化を」
**設計原則:**
- アクセシビリティ最優先 — WCAG 2.2 AA / JIS X 8341-3:2016 準拠
- 装飾より情報階層 — クリーンでミニマルなレイアウト
- カラーのみに依存しない情報伝達(色覚多様性への配慮)
- 日英バイリンガル対応(日本語 + 英語の混在コンテンツ)
**実装スタック:** Tailwind CSS + `@digital-go-jp/tailwind-theme-plugin`、React コンポーネントと素の HTML コンポーネントを両方提供。デザインデータは Figma Community で公開。
---
## Colors
### ロゴカラー
ロゴは単色。背景色への適応のため、黒版・白版の SVG が用意されている。
| Role | Hex | 証拠 |
|---|---|---|
| Logo Black | `#252020` | `logo.svg` / `logo-en.svg` の fill 値から直接抽出 |
### Primary Action Color (推定)
ブルーが主要インタラクション色。ボタンドキュメントの「青背景に白テキスト」から Blue-700 を primary として推定。Figma のセマンティックトークンで正式定義されているが、公開 CSS には含まれない。
| Role | Hex | Notes |
|---|---|---|
| Primary (推定) | `#3460fb` | Blue-700 — 主要ボタン・フォーカスリング |
| Primary Hover (推定) | `#264af4` | Blue-800 |
| Primary Active (推定) | `#0031d8` | Blue-900 |
### ブルー — プリミティブスケール (13段階)
| Token | Hex | 明度 |
|---|---|---|
| Blue-100 | `#e8f1fe` | 最も薄い |
| Blue-200 | `#d9e6ff` | |
| Blue-300 | `#c5d7fb` | |
| Blue-400 | `#9db7f9` | |
| Blue-500 | `#7096f8` | |
| Blue-600 | `#4979f5` | |
| **Blue-700** | **`#3460fb`** | **Primary 推定** |
| Blue-800 | `#264af4` | |
| Blue-900 | `#0031d8` | |
| Blue-1000 | `#0017c1` | |
| Blue-1100 | `#00118f` | |
| Blue-1200 | `#000071` | |
| Blue-1300 | `#000060` | 最も濃い |
その他のプリミティブカラー (各13段階): LightBlue / Cyan / Green / Lime / Yellow / Orange / Red / Magenta / Purple
### ニュートラル — SolidGray (12段階)
アクセシビリティ上の意味を持つキーグレー値。
| Token | Hex | コントラスト比 |
|---|---|---|
| Gray-50 | `#f2f2f2` | ページ背景 |
| Gray-100 | `#e6e6e6` | ボーダー (薄) |
| Gray-200 | `#cccccc` | |
| Gray-300 | `#b3b3b3` | |
| Gray-400 | `#999999` | |
| **Gray-420** | **`#949494`** | **3:1 vs White — 非テキスト最小値** |
| Gray-500 | `#7f7f7f` | |
| **Gray-536** | **`#767676`** | **4.5:1 vs White — テキスト最小値** |
| **Gray-600** | **`#666666`** | **3:1 vs Black** |
| Gray-700 | `#4d4d4d` | |
| Gray-800 | `#333333` | |
| Gray-900 | `#1a1a1a` | 本文テキスト推奨 |
OpacityGray: `rgba(0,0,0, 0.05–0.9)` の12段階 (5/10/20/30/40/42/50/53.6/60/70/80/90%) — SolidGray の各段階に対応。
### セマンティックカラー
figma/tokens.json から直接抽出。
| Role | Hex | Source Token |
|---|---|---|
| Success | `#259d63` | Green-600 |
| Success Dark (hover/active) | `#197a4b` | Green-800 |
| Error | `#ec0000` | Red-800 |
| Error Dark | `#ce0000` | Red-900 |
| Warning Yellow | `#b78f00` | Yellow-700 |
| Warning Yellow Dark | `#927200` | Yellow-900 |
| Warning Orange | `#fb5b01` | Orange-600 |
| Warning Orange Dark | `#c74700` | Orange-800 |
| Link Default (推定) | Blue | Figma で定義、公開値なし |
| Link Visited (推定) | Magenta | 青との混同を避けるため Purple より Magenta を推奨 |
---
## Typography
### フォントファミリー
フォントは Noto Sans JP のみ。日英混在コンテンツに最適化。中間ウェイト (500/600) は使用しない。
```css
--font-sans: 'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif;
--font-mono: 'Noto Sans Mono', monospace;
```
Noto Sans JP のライセンス: SIL Open Font License 1.1
### フォントウェイト
| Name | Value |
|---|---|
| Normal (N) | `400` |
| Bold (B) | `700` |
### フォントサイズスケール (15段階)
| Token | px |
|---|---|
| xs | 14 |
| sm | 16 |
| sm2 | 17 |
| md | 18 |
| md2 | 20 |
| md3 | 22 |
| lg | 24 |
| lg2 | 26 |
| xl | 28 |
| xl2 | 32 |
| xl3 | 36 |
| xl4 | 45 |
| display-sm | 48 |
| display-md | 57 |
| display-lg | 64 |
### テキストスタイルカテゴリ
| Category | 略称 | Size Range | Line Height | 用途 |
|---|---|---|---|---|
| Display | Dsp | 48–64px | 140% | ヒーロー・大見出し (6スタイル) |
| Standard | Std | 16–45px | 150–175% | 一般本文・見出し (Bold×12 + Normal×12) |
| Dense | Dns | 14–17px | 140–150% | データ集約UI、小テキスト (Bold×6 + Normal×6) |
| Oneline | Oln | 16–28px | **100%** | UIラベル・ボタンテキスト (6スタイル) |
| Mono | — | 14–24px | 150% | コード表示 (6スタイル) |
ボタンには **Oneline スタイル** (line-height: 100%) を使用すること。
---
## Spacing
8px をベースユニットとするモジュラースケール。
| Scale | px | 使用例 |
|---|---|---|
| 1× | 8 | コンポーネント内最小パディング |
| 2× | 16 | 標準的な要素間隔 |
| 3× | 24 | セクション内グループ間隔 |
| 4× | 32 | |
| 5× | 40 | |
| 6× | 48 | セクション間 |
| 8× | 64 | 大セクション区切り |
スペースはコンポーネントに統合して使用する。スタンドアロントークンとして参照する場面は限定的。
---
## Layout
12カラムグリッド、ブレイクポイント1つのシンプルな構造。
| Device | Viewport |
|---|---|
| Mobile & Tablet | < 768px |
| Desktop | ≥ 768px |
### カラム分割パターン
| パターン | カラム比 |
|---|---|
| シングル | 12 |
| メイン + サイドナロー | 9 / 3 |
| サイドナロー + メイン | 3 / 9 |
| コンテンツ + サイドバー | 8 / 4, 4 / 8 |
| ハーフ | 6 / 6 |
| 3カラム均等 | 4 / 4 / 4 |
| 3カラム中央強調 | 3 / 6 / 3 |
**ガター幅:** 本文文字サイズ × 2 以上(例: 16px × 2 = 32px)。
左ナビゲーション固定幅 + コンテンツエリアの2ペインが標準レイアウト。
---
## Corner Shapes (Border Radius)
| Token | Value | 推奨用途 |
|---|---|---|
| sm | `4px` | チップ、バッジ、タグ |
| md | `6px` | |
| lg | `8px` | **ボタン、テキスト入力** |
| xl | `12px` | **カード** |
| 2xl | `16px` | |
| 3xl | `24px` | パネル、モーダルダイアログ |
| 4xl | `32px` | |
| full | `9999px` | ピル形状、アバター、検索バー |
---
## Elevation
8段階のドロップシャドウスケール。各レベルは二重レイヤー構造(アンビエント + ディレクショナル)。
| Level | 用途 |
|---|---|
| 0 | 平面 (シャドウなし) |
| 1 | カード (通常状態) |
| 2 | カード (ホバー)、ドロップダウン |
| 3–4 | フローティングUI、ツールチップ |
| 5–6 | モーダル、ダイアログ |
| 7–8 | 最上位レイヤー |
モーダル背景のオーバーレイシェード: `rgba(0,0,0, 0.x)` の半透明ダーク。
---
## Components
### Button (ボタン)
**3種類のボタンタイプ:**
| Type | Background | Text Color | Border | 重要度 |
|---|---|---|---|---|
| Filled | `#3460fb` (Blue-700, 推定) | `#ffffff` | なし | 高 |
| Outline | `#ffffff` / 透明 | `#3460fb` | `1px solid` Blue | 中 |
| Text | 透明 | `#3460fb` | なし (下線) | 低 |
**4サイズ (ドキュメントから直接抽出):**
| Size | Min Width | Height |
|---|---|---|
| Large | 136px | 56px |
| Medium | 96px | 48px |
| Small | 80px | 36px |
| X-Small | 72px | 28px |
最小タッチターゲット: **44px**(高さが不足する場合はパディングで補完)。
幅はラベル長に応じて可変(flex padding モデル)。
フォント: Oneline スタイル (line-height: 100%)。
**ステート:** Default → Hover (暗色化) → Active (さらに暗色化) → Focus (リング表示) → Disabled
---
### Card (カード)
単一トピックのコンテンツをグルーピングするフレキシブルコンテナ。
- Background: `#ffffff`
- Border-radius: `12px` (xl) ― 推定
- Shadow: Elevation Level 1–2
- 構成要素: サムネイル画像 + 見出し + 本文 + リンク/アクション
---
### Notification Banner (通知バナー)
**カラー × ステータス:**
| Type | Background Color | Icon | Source Token |
|---|---|---|---|
| Success | `#259d63` | ✓ | Green-600 |
| Error | `#ec0000` | × | Red-800 |
| Warning Yellow | `#b78f00` | ! | Yellow-700 |
| Warning Orange | `#fb5b01` | ! | Orange-600 |
| Info 1 | Blue (primary) | ℹ | — |
| Info 2 | `#000000` | ℹ | — |
**2スタイル:**
- **Standard**: 角丸ボーダー
- **Color Chip**: 左側に太いアクセントボーダー (border-left)
Emergency Banner (緊急時バナー) は別コンポーネント。最高優先度で表示。
---
### Text Input (テキスト入力)
状態: Default / Hover / Focus / Error / Disabled
Focus: ブルーのフォーカスリング
Error: 赤ボーダー (`#ec0000`) + エラーメッセージテキスト
---
### 47コンポーネント一覧 (カテゴリ別)
**ナビゲーション:** グローバルメニュー、ボトムナビゲーション、ページナビゲーション、パンくずリスト、メガメニュー、メニューリスト、メニューリストボックス、モバイルメニュー、ハンバーガーメニューボタン
**フォームコントロール:** インプットテキスト、テキストエリア、セレクトボックス、チェックボックス、ラジオボタン、コンボボックス、日付ピッカー/カレンダー、ファイルアップロード/ドロップエリア
**コンテンツ:** ボタン、カード、見出し、画像、箇条書きリスト、説明リスト、引用ブロック、テーブル/データテーブル、テーブルコントロール
**インジケーター/フィードバック:** プログレスインジケーター、ノティフィケーションバナー、緊急時バナー、チップラベル、チップタグ
**インタラクティブ:** アコーディオン、タブ、ディスクロージャー、ドロワー、モーダルダイアログ、イメージスライダー、カルーセル
**ユーティリティ:** ディバイダー、ヘッダーコンテナ、スクロールトップボタン、ステップナビゲーション、検索ボックス、ユーティリティリンク、ランゲージセレクター、リソースリスト
---
## Imagery
### イラスト
公式イラストリソースが提供されており、行政手続きを分かりやすくするために設計されています。
スタイル: フラットなベクターイラスト、親しみやすいキャラクター、インクルーシブな人物表現(多様な職業・年齢・性別)。
### フォトグラフィー
- 現実の人々・職場・サービスシーンを使用
- 医療、教育、ビジネスなど行政サービスのコンテキスト
- インクルーシブな表現を重視
### アイコン
ドキュメント構造内の位置に基づく4種類の仕様。シンプルで認識しやすいUIアイコン。カラーは周囲のテキストまたは意味的な色(success/error/warning)に準じる。
---
## Logo and Usage
- **デザイン:** 「デジタル庁 Digital Agency」横並びワードマーク
- **フォーマット:** SVG (すべてパスで描画、システムフォントに依存しない)
- **日本語版 viewBox:** `0 0 1746.36 320`
- **英語版 viewBox:** `0 0 2429.14 336`
- **標準色:** `#252020` (SVG fill 値から直接抽出) — 濃いチャコールブラック
- **背景:** 白背景を前提とした設計
- **ロゴ使用:** 申請が必要 (公式ガイドラインに従う)
---
## Do's and Don'ts
### Do
- **Noto Sans JP** のみを使用する — 他フォントへの切り替え不可
- ブルーを主要インタラクション色として一貫して使用する
- 本文テキストには `Gray-900` (`#1a1a1a`) を基本にする
- テキストの最低コントラスト比: **4.5:1** (WCAG 2.2 AA)
- 非テキスト要素の最低コントラスト比: **3:1**
- フォーカスインジケーターを必ず視覚的に明示する
- ボタンの最小タッチターゲットを **44px** に保つ
- 8px グリッドでスペースを定義する
- カラーと非カラーの両方の手がかりで情報を伝える
- ボタンはページ内の重要度順に Filled → Outline → Text と使い分ける
### Don't
- `Gray-420` (`#949494`) より薄いグレーをテキストに使用しない
- `Gray-536` (`#767676`) より薄いグレーをテキストコントラストとして使用しない
- プライマリ (Filled) ボタンを複数並べて重要度を希釈しない
- ロゴを変形・再彩色・トリミングしない
- フォントウェイト 500/600 を使用しない (400 と 700 のみ)
- リンクの visited 色 (Magenta/Purple) をナビゲーション要素に転用しない
- カラーのみで情報を伝えない (アイコン・ラベル・パターンを併用する)
---
## Accessibility
| 規格 | 準拠レベル |
|---|---|
| WCAG 2.2 | AA |
| JIS X 8341-3:2016 | 準拠 |
- **テキストコントラスト:** 4.5:1 以上
- **非テキストコントラスト:** 3:1 以上 (ボーダー、アイコン、グラフ)
- **色覚多様性対応:** C型・P型・D型シミュレーション実施済み — カラーのみに依存しない設計
- **visited リンク:** 青との混同リスクがあるため Purple より Magenta を推奨
- **タッチターゲット:** 最小 44px × 44px
- **フォーカス管理:** モーダル・ドロワー開閉時のフォーカストラップ対応コンポーネントを提供
デジタル庁 (Digital Agency Japan)
「誰一人取り残されない、人に優しいデジタル化を」をミッションとする日本のデジタル庁公式デザインシステム (DADS) v2.13.0。WCAG 2.2 AA / JIS X 8341-3:2016 準拠の政府向け UI 言語で、Noto Sans JP 単一フォントスタックと 13 段階のブルースケール (#e8f1fe → #000060) を基盤に、装飾より情報階層を重視したクリーンでミニマルなレイアウトを定義。最小タッチターゲット 44px、テキストコントラスト 4.5:1 以上、色覚多様性 (C/P/D 型) 検証済みなど、アクセシビリティ制約を設計レベルで組み込んでいる。デザインデータは Figma Community で公開、実装は Tailwind CSS プラグイン + React / 素の HTML コンポーネントの両形態で提供。日英バイリンガル対応。

Color Palette
Primary Action (推定)
Blue Scale (13 Levels)
Neutrals (SolidGray 12 Levels)
Semantic Status
Logo
Typography
Fonts
Noto Sans JP
primary'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif
本文・見出し・UI 全般。SIL Open Font License 1.1。日英混在コンテンツに最適化、中間ウェイト (500/600) は使用しない設計判断
Noto Sans Mono
mono'Noto Sans Mono', monospace
コードブロック・等幅表示用 (14px〜24px の 6 スタイル)
Type Scale
他 1 件を省略
日本語タイポグラフィ
禁則処理・行間・字間・OpenType 機能の設定
- フォントスタック
'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif- 行間
- 1.75(欧文 1.43 に対し約 22% 広い)
- 字間
- 0
- 禁則処理
word-break: keep-allline-break: strict- OpenType
- palt(プロポーショナル仮名): offkern: on
「日本語タイポグラフィの再現」
私たちは、文字の美しさと読みやすさを両立させるデザインを追求しています。 Webフォントは表示速度に影響しますが、適切な行間(line-height)と字間 (letter-spacing)を設定することで、可読性が向上します。 禁則処理を適用することで、行末に句読点や括弧が来るのを防ぎます。
※ Noto Sans JP の単一スタック (他フォントへの切り替えは Don't 違反)ウェイトは 400 / 700 のみ運用、500 / 600 は使用しない本文 line-height は 1.75 (175%) を採用、日本語の可読性を優先ボタン・UI ラベルには Oneline (line-height: 1.0) を使う
Spacing
ベースユニット: 8px
8pxコンポーネント内最小パディング16px標準的な要素間隔24pxセクション内グループ間隔32px中間スペース・ガター幅 (本文 16px × 2)40px中余白48pxセクション間64px大セクション区切りShape
Border Radius
sm
4px
md
6px
lg
8px
xl
12px
2xl
16px
3xl
24px
4xl
32px
full
9999px
Components
Button
Filled Button (Primary)
プライマリブルー背景のメイン CTA。重要度高。最小タッチターゲット 44px、ボタンテキストは Oneline スタイル (line-height: 100%)
Outline Button (Secondary)
白背景 + ブルー 1px 枠のセカンダリボタン。重要度中
Text Button (Tertiary)
透明背景 + 下線のテキストボタン。重要度低
Card
Card
単一トピックをグルーピングする白背景コンテナ。サムネイル + 見出し + 本文 + リンク/アクションで構成
input
Text Input
標準テキスト入力。フォーカスでブルーリング、エラーで赤ボーダー
Default
Focus
Error
Disabled
banner
Notification Banner
ステータス通知バナー。Standard (角丸全体) / Color Chip (左側に太いアクセントボーダー) の 2 スタイル。アイコン + テキストで色覚多様性に配慮
Success
Error
Warning Yellow
Warning Orange
Info Blue
Info Black
chip
Chip / Tag
ピル形状のラベル要素。状態表示・カテゴリ分類用
Default
focus
Focus Ring
フォーカス状態の視覚インジケーター。すべてのインタラクティブ要素に必須
Default
Guidelines
Do
- Noto Sans JP のみを使用する — 他フォントへの切り替えは不可
- ブルーを主要インタラクション色として一貫して使用する (Blue-700: #3460fb)
- 本文テキストには Gray-900 (#1a1a1a) を基本にする
- テキストの最低コントラスト比 4.5:1 を維持する (WCAG 2.2 AA)
- 非テキスト要素の最低コントラスト比 3:1 を維持する
- フォーカスインジケーターを必ず視覚的に明示する
- ボタンの最小タッチターゲットを 44px × 44px に保つ
- 8px グリッドでスペースを定義する
- カラーとアイコン/ラベル/パターンの両方で情報を伝える (色覚多様性対応)
- ボタンはページ内の重要度順に Filled → Outline → Text と使い分ける
- ボタンには Oneline スタイル (line-height: 100%) を使う
Don't
- Gray-420 (#949494) より薄いグレーをテキストに使用しない
- Gray-536 (#767676) より薄いグレーをテキストコントラストとして使用しない
- プライマリ (Filled) ボタンを複数並べて重要度を希釈しない
- ロゴを変形・再彩色・トリミングしない (#252020 の単色のみ)
- フォントウェイト 500 / 600 を使用しない (400 と 700 のみ)
- リンクの visited 色 (Magenta/Purple) をナビゲーション要素に転用しない
- カラーのみで情報を伝えない (アイコン・ラベル・パターンを併用する)
- プライマリ青をテキストの大段落色として使わない (リンクとの識別不可)
---
version: "2.13.0"
name: デジタル庁 (Digital Agency Japan)
description: 日本のデジタル庁公式デザインシステム (DADS) — アクセシビリティ優先の政府向けUI言語。Noto Sans JP とブルー主体のトークンパレットで WCAG 2.2 準拠を実現する。
sources:
- https://www.digital.go.jp/
- https://design.digital.go.jp/
- https://design.digital.go.jp/foundations/color/
- https://design.digital.go.jp/foundations/typography/
- https://design.digital.go.jp/foundations/spacing/
- https://design.digital.go.jp/foundations/layout/
- https://design.digital.go.jp/foundations/elevation/
- https://design.digital.go.jp/components/button/
- https://design.digital.go.jp/components/
- https://raw.githubusercontent.com/digital-go-jp/design-tokens/main/figma/tokens.json
notes:
- 全カラー値は digital-go-jp/design-tokens リポジトリの figma/tokens.json から直接抽出。直接証拠。
- セマンティックカラー (primary, link) は Figma で定義されているが CSS 非公開のため、ボタンドキュメントと公式サイト観察から推定。
- ロゴ色 (#252020) は /themes/custom/gov_theme_da_2023/logo.svg の fill 値から直接抽出。
- エレベーション (shadow) の具体的な CSS 値は非公開。8段階の構造のみ文書化。
- ボタンサイズ (px) はコンポーネントドキュメントから直接抽出。
- WCAG 2.2 / JIS X 8341-3:2016 準拠は設計上の制約として明示されている。
colors:
# --- ロゴ ---
logo: "#252020"
# --- ブルー (13段階) ---
blue-100: "#e8f1fe"
blue-200: "#d9e6ff"
blue-300: "#c5d7fb"
blue-400: "#9db7f9"
blue-500: "#7096f8"
blue-600: "#4979f5"
blue-700: "#3460fb"
blue-800: "#264af4"
blue-900: "#0031d8"
blue-1000: "#0017c1"
blue-1100: "#00118f"
blue-1200: "#000071"
blue-1300: "#000060"
# --- ニュートラル ---
white: "#ffffff"
black: "#000000"
gray-50: "#f2f2f2"
gray-100: "#e6e6e6"
gray-200: "#cccccc"
gray-300: "#b3b3b3"
gray-400: "#999999"
gray-420: "#949494"
gray-500: "#7f7f7f"
gray-536: "#767676"
gray-600: "#666666"
gray-700: "#4d4d4d"
gray-800: "#333333"
gray-900: "#1a1a1a"
# --- セマンティック ---
success: "#259d63"
success-dark: "#197a4b"
error: "#ec0000"
error-dark: "#ce0000"
warning-yellow: "#b78f00"
warning-yellow-dark: "#927200"
warning-orange: "#fb5b01"
warning-orange-dark: "#c74700"
typography:
display:
fontFamily: "'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif"
fontSize: "48px–64px"
lineHeight: "140%"
fontWeight: 700
h1:
fontFamily: "'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif"
fontSize: "36px"
lineHeight: "150%"
fontWeight: 700
h2:
fontFamily: "'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif"
fontSize: "32px"
lineHeight: "150%"
fontWeight: 700
body:
fontFamily: "'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif"
fontSize: "16px"
lineHeight: "175%"
fontWeight: 400
label:
fontFamily: "'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif"
fontSize: "16px"
lineHeight: "100%"
fontWeight: 400
mono:
fontFamily: "'Noto Sans Mono', monospace"
fontSize: "14px–24px"
lineHeight: "150%"
fontWeight: 400
rounded:
sm: "4px"
md: "6px"
lg: "8px"
xl: "12px"
2xl: "16px"
3xl: "24px"
4xl: "32px"
full: "9999px"
spacing:
base: "8px"
components:
button-filled:
backgroundColor: "{colors.blue-700}"
color: "{colors.white}"
borderRadius: "{rounded.lg}"
minTouchTarget: "44px"
button-outline:
backgroundColor: "{colors.white}"
color: "{colors.blue-700}"
border: "1px solid {colors.blue-700}"
borderRadius: "{rounded.lg}"
button-text:
backgroundColor: "transparent"
color: "{colors.blue-700}"
textDecoration: "underline"
---
## Overview
デジタル庁デザインシステム (DADS) は、日本の政府・公共機関向けウェブサイトおよびアプリケーションのための公式デザイン言語。バージョン 2.13.0 (2024年5月30日 β版公開)。
**ミッション:** 「誰一人取り残されない、人に優しいデジタル化を」
**設計原則:**
- アクセシビリティ最優先 — WCAG 2.2 AA / JIS X 8341-3:2016 準拠
- 装飾より情報階層 — クリーンでミニマルなレイアウト
- カラーのみに依存しない情報伝達(色覚多様性への配慮)
- 日英バイリンガル対応(日本語 + 英語の混在コンテンツ)
**実装スタック:** Tailwind CSS + `@digital-go-jp/tailwind-theme-plugin`、React コンポーネントと素の HTML コンポーネントを両方提供。デザインデータは Figma Community で公開。
---
## Colors
### ロゴカラー
ロゴは単色。背景色への適応のため、黒版・白版の SVG が用意されている。
| Role | Hex | 証拠 |
|---|---|---|
| Logo Black | `#252020` | `logo.svg` / `logo-en.svg` の fill 値から直接抽出 |
### Primary Action Color (推定)
ブルーが主要インタラクション色。ボタンドキュメントの「青背景に白テキスト」から Blue-700 を primary として推定。Figma のセマンティックトークンで正式定義されているが、公開 CSS には含まれない。
| Role | Hex | Notes |
|---|---|---|
| Primary (推定) | `#3460fb` | Blue-700 — 主要ボタン・フォーカスリング |
| Primary Hover (推定) | `#264af4` | Blue-800 |
| Primary Active (推定) | `#0031d8` | Blue-900 |
### ブルー — プリミティブスケール (13段階)
| Token | Hex | 明度 |
|---|---|---|
| Blue-100 | `#e8f1fe` | 最も薄い |
| Blue-200 | `#d9e6ff` | |
| Blue-300 | `#c5d7fb` | |
| Blue-400 | `#9db7f9` | |
| Blue-500 | `#7096f8` | |
| Blue-600 | `#4979f5` | |
| **Blue-700** | **`#3460fb`** | **Primary 推定** |
| Blue-800 | `#264af4` | |
| Blue-900 | `#0031d8` | |
| Blue-1000 | `#0017c1` | |
| Blue-1100 | `#00118f` | |
| Blue-1200 | `#000071` | |
| Blue-1300 | `#000060` | 最も濃い |
その他のプリミティブカラー (各13段階): LightBlue / Cyan / Green / Lime / Yellow / Orange / Red / Magenta / Purple
### ニュートラル — SolidGray (12段階)
アクセシビリティ上の意味を持つキーグレー値。
| Token | Hex | コントラスト比 |
|---|---|---|
| Gray-50 | `#f2f2f2` | ページ背景 |
| Gray-100 | `#e6e6e6` | ボーダー (薄) |
| Gray-200 | `#cccccc` | |
| Gray-300 | `#b3b3b3` | |
| Gray-400 | `#999999` | |
| **Gray-420** | **`#949494`** | **3:1 vs White — 非テキスト最小値** |
| Gray-500 | `#7f7f7f` | |
| **Gray-536** | **`#767676`** | **4.5:1 vs White — テキスト最小値** |
| **Gray-600** | **`#666666`** | **3:1 vs Black** |
| Gray-700 | `#4d4d4d` | |
| Gray-800 | `#333333` | |
| Gray-900 | `#1a1a1a` | 本文テキスト推奨 |
OpacityGray: `rgba(0,0,0, 0.05–0.9)` の12段階 (5/10/20/30/40/42/50/53.6/60/70/80/90%) — SolidGray の各段階に対応。
### セマンティックカラー
figma/tokens.json から直接抽出。
| Role | Hex | Source Token |
|---|---|---|
| Success | `#259d63` | Green-600 |
| Success Dark (hover/active) | `#197a4b` | Green-800 |
| Error | `#ec0000` | Red-800 |
| Error Dark | `#ce0000` | Red-900 |
| Warning Yellow | `#b78f00` | Yellow-700 |
| Warning Yellow Dark | `#927200` | Yellow-900 |
| Warning Orange | `#fb5b01` | Orange-600 |
| Warning Orange Dark | `#c74700` | Orange-800 |
| Link Default (推定) | Blue | Figma で定義、公開値なし |
| Link Visited (推定) | Magenta | 青との混同を避けるため Purple より Magenta を推奨 |
---
## Typography
### フォントファミリー
フォントは Noto Sans JP のみ。日英混在コンテンツに最適化。中間ウェイト (500/600) は使用しない。
```css
--font-sans: 'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif;
--font-mono: 'Noto Sans Mono', monospace;
```
Noto Sans JP のライセンス: SIL Open Font License 1.1
### フォントウェイト
| Name | Value |
|---|---|
| Normal (N) | `400` |
| Bold (B) | `700` |
### フォントサイズスケール (15段階)
| Token | px |
|---|---|
| xs | 14 |
| sm | 16 |
| sm2 | 17 |
| md | 18 |
| md2 | 20 |
| md3 | 22 |
| lg | 24 |
| lg2 | 26 |
| xl | 28 |
| xl2 | 32 |
| xl3 | 36 |
| xl4 | 45 |
| display-sm | 48 |
| display-md | 57 |
| display-lg | 64 |
### テキストスタイルカテゴリ
| Category | 略称 | Size Range | Line Height | 用途 |
|---|---|---|---|---|
| Display | Dsp | 48–64px | 140% | ヒーロー・大見出し (6スタイル) |
| Standard | Std | 16–45px | 150–175% | 一般本文・見出し (Bold×12 + Normal×12) |
| Dense | Dns | 14–17px | 140–150% | データ集約UI、小テキスト (Bold×6 + Normal×6) |
| Oneline | Oln | 16–28px | **100%** | UIラベル・ボタンテキスト (6スタイル) |
| Mono | — | 14–24px | 150% | コード表示 (6スタイル) |
ボタンには **Oneline スタイル** (line-height: 100%) を使用すること。
---
## Spacing
8px をベースユニットとするモジュラースケール。
| Scale | px | 使用例 |
|---|---|---|
| 1× | 8 | コンポーネント内最小パディング |
| 2× | 16 | 標準的な要素間隔 |
| 3× | 24 | セクション内グループ間隔 |
| 4× | 32 | |
| 5× | 40 | |
| 6× | 48 | セクション間 |
| 8× | 64 | 大セクション区切り |
スペースはコンポーネントに統合して使用する。スタンドアロントークンとして参照する場面は限定的。
---
## Layout
12カラムグリッド、ブレイクポイント1つのシンプルな構造。
| Device | Viewport |
|---|---|
| Mobile & Tablet | < 768px |
| Desktop | ≥ 768px |
### カラム分割パターン
| パターン | カラム比 |
|---|---|
| シングル | 12 |
| メイン + サイドナロー | 9 / 3 |
| サイドナロー + メイン | 3 / 9 |
| コンテンツ + サイドバー | 8 / 4, 4 / 8 |
| ハーフ | 6 / 6 |
| 3カラム均等 | 4 / 4 / 4 |
| 3カラム中央強調 | 3 / 6 / 3 |
**ガター幅:** 本文文字サイズ × 2 以上(例: 16px × 2 = 32px)。
左ナビゲーション固定幅 + コンテンツエリアの2ペインが標準レイアウト。
---
## Corner Shapes (Border Radius)
| Token | Value | 推奨用途 |
|---|---|---|
| sm | `4px` | チップ、バッジ、タグ |
| md | `6px` | |
| lg | `8px` | **ボタン、テキスト入力** |
| xl | `12px` | **カード** |
| 2xl | `16px` | |
| 3xl | `24px` | パネル、モーダルダイアログ |
| 4xl | `32px` | |
| full | `9999px` | ピル形状、アバター、検索バー |
---
## Elevation
8段階のドロップシャドウスケール。各レベルは二重レイヤー構造(アンビエント + ディレクショナル)。
| Level | 用途 |
|---|---|
| 0 | 平面 (シャドウなし) |
| 1 | カード (通常状態) |
| 2 | カード (ホバー)、ドロップダウン |
| 3–4 | フローティングUI、ツールチップ |
| 5–6 | モーダル、ダイアログ |
| 7–8 | 最上位レイヤー |
モーダル背景のオーバーレイシェード: `rgba(0,0,0, 0.x)` の半透明ダーク。
---
## Components
### Button (ボタン)
**3種類のボタンタイプ:**
| Type | Background | Text Color | Border | 重要度 |
|---|---|---|---|---|
| Filled | `#3460fb` (Blue-700, 推定) | `#ffffff` | なし | 高 |
| Outline | `#ffffff` / 透明 | `#3460fb` | `1px solid` Blue | 中 |
| Text | 透明 | `#3460fb` | なし (下線) | 低 |
**4サイズ (ドキュメントから直接抽出):**
| Size | Min Width | Height |
|---|---|---|
| Large | 136px | 56px |
| Medium | 96px | 48px |
| Small | 80px | 36px |
| X-Small | 72px | 28px |
最小タッチターゲット: **44px**(高さが不足する場合はパディングで補完)。
幅はラベル長に応じて可変(flex padding モデル)。
フォント: Oneline スタイル (line-height: 100%)。
**ステート:** Default → Hover (暗色化) → Active (さらに暗色化) → Focus (リング表示) → Disabled
---
### Card (カード)
単一トピックのコンテンツをグルーピングするフレキシブルコンテナ。
- Background: `#ffffff`
- Border-radius: `12px` (xl) ― 推定
- Shadow: Elevation Level 1–2
- 構成要素: サムネイル画像 + 見出し + 本文 + リンク/アクション
---
### Notification Banner (通知バナー)
**カラー × ステータス:**
| Type | Background Color | Icon | Source Token |
|---|---|---|---|
| Success | `#259d63` | ✓ | Green-600 |
| Error | `#ec0000` | × | Red-800 |
| Warning Yellow | `#b78f00` | ! | Yellow-700 |
| Warning Orange | `#fb5b01` | ! | Orange-600 |
| Info 1 | Blue (primary) | ℹ | — |
| Info 2 | `#000000` | ℹ | — |
**2スタイル:**
- **Standard**: 角丸ボーダー
- **Color Chip**: 左側に太いアクセントボーダー (border-left)
Emergency Banner (緊急時バナー) は別コンポーネント。最高優先度で表示。
---
### Text Input (テキスト入力)
状態: Default / Hover / Focus / Error / Disabled
Focus: ブルーのフォーカスリング
Error: 赤ボーダー (`#ec0000`) + エラーメッセージテキスト
---
### 47コンポーネント一覧 (カテゴリ別)
**ナビゲーション:** グローバルメニュー、ボトムナビゲーション、ページナビゲーション、パンくずリスト、メガメニュー、メニューリスト、メニューリストボックス、モバイルメニュー、ハンバーガーメニューボタン
**フォームコントロール:** インプットテキスト、テキストエリア、セレクトボックス、チェックボックス、ラジオボタン、コンボボックス、日付ピッカー/カレンダー、ファイルアップロード/ドロップエリア
**コンテンツ:** ボタン、カード、見出し、画像、箇条書きリスト、説明リスト、引用ブロック、テーブル/データテーブル、テーブルコントロール
**インジケーター/フィードバック:** プログレスインジケーター、ノティフィケーションバナー、緊急時バナー、チップラベル、チップタグ
**インタラクティブ:** アコーディオン、タブ、ディスクロージャー、ドロワー、モーダルダイアログ、イメージスライダー、カルーセル
**ユーティリティ:** ディバイダー、ヘッダーコンテナ、スクロールトップボタン、ステップナビゲーション、検索ボックス、ユーティリティリンク、ランゲージセレクター、リソースリスト
---
## Imagery
### イラスト
公式イラストリソースが提供されており、行政手続きを分かりやすくするために設計されています。
スタイル: フラットなベクターイラスト、親しみやすいキャラクター、インクルーシブな人物表現(多様な職業・年齢・性別)。
### フォトグラフィー
- 現実の人々・職場・サービスシーンを使用
- 医療、教育、ビジネスなど行政サービスのコンテキスト
- インクルーシブな表現を重視
### アイコン
ドキュメント構造内の位置に基づく4種類の仕様。シンプルで認識しやすいUIアイコン。カラーは周囲のテキストまたは意味的な色(success/error/warning)に準じる。
---
## Logo and Usage
- **デザイン:** 「デジタル庁 Digital Agency」横並びワードマーク
- **フォーマット:** SVG (すべてパスで描画、システムフォントに依存しない)
- **日本語版 viewBox:** `0 0 1746.36 320`
- **英語版 viewBox:** `0 0 2429.14 336`
- **標準色:** `#252020` (SVG fill 値から直接抽出) — 濃いチャコールブラック
- **背景:** 白背景を前提とした設計
- **ロゴ使用:** 申請が必要 (公式ガイドラインに従う)
---
## Do's and Don'ts
### Do
- **Noto Sans JP** のみを使用する — 他フォントへの切り替え不可
- ブルーを主要インタラクション色として一貫して使用する
- 本文テキストには `Gray-900` (`#1a1a1a`) を基本にする
- テキストの最低コントラスト比: **4.5:1** (WCAG 2.2 AA)
- 非テキスト要素の最低コントラスト比: **3:1**
- フォーカスインジケーターを必ず視覚的に明示する
- ボタンの最小タッチターゲットを **44px** に保つ
- 8px グリッドでスペースを定義する
- カラーと非カラーの両方の手がかりで情報を伝える
- ボタンはページ内の重要度順に Filled → Outline → Text と使い分ける
### Don't
- `Gray-420` (`#949494`) より薄いグレーをテキストに使用しない
- `Gray-536` (`#767676`) より薄いグレーをテキストコントラストとして使用しない
- プライマリ (Filled) ボタンを複数並べて重要度を希釈しない
- ロゴを変形・再彩色・トリミングしない
- フォントウェイト 500/600 を使用しない (400 と 700 のみ)
- リンクの visited 色 (Magenta/Purple) をナビゲーション要素に転用しない
- カラーのみで情報を伝えない (アイコン・ラベル・パターンを併用する)
---
## Accessibility
| 規格 | 準拠レベル |
|---|---|
| WCAG 2.2 | AA |
| JIS X 8341-3:2016 | 準拠 |
- **テキストコントラスト:** 4.5:1 以上
- **非テキストコントラスト:** 3:1 以上 (ボーダー、アイコン、グラフ)
- **色覚多様性対応:** C型・P型・D型シミュレーション実施済み — カラーのみに依存しない設計
- **visited リンク:** 青との混同リスクがあるため Purple より Magenta を推奨
- **タッチターゲット:** 最小 44px × 44px
- **フォーカス管理:** モーダル・ドロワー開閉時のフォーカストラップ対応コンポーネントを提供
{
"$schema": "https://aistyles.dev/schema/tokens-v1.json",
"version": "1.0",
"brand": {
"slug": "digital",
"name": "デジタル庁 (Digital Agency Japan)",
"url": "https://www.digital.go.jp/",
"description": "「誰一人取り残されない、人に優しいデジタル化を」をミッションとする日本のデジタル庁公式デザインシステム (DADS) v2.13.0。WCAG 2.2 AA / JIS X 8341-3:2016 準拠の政府向け UI 言語で、Noto Sans JP 単一フォントスタックと 13 段階のブルースケール (#e8f1fe → #000060) を基盤に、装飾より情報階層を重視したクリーンでミニマルなレイアウトを定義。最小タッチターゲット 44px、テキストコントラスト 4.5:1 以上、色覚多様性 (C/P/D 型) 検証済みなど、アクセシビリティ制約を設計レベルで組み込んでいる。デザインデータは Figma Community で公開、実装は Tailwind CSS プラグイン + React / 素の HTML コンポーネントの両形態で提供。日英バイリンガル対応。",
"category": "infrastructure",
"tags": [
"infrastructure",
"minimal"
],
"theme": "light",
"language": "ja"
},
"sources": [
"https://www.digital.go.jp/",
"https://design.digital.go.jp/",
"https://design.digital.go.jp/foundations/color/",
"https://design.digital.go.jp/foundations/typography/",
"https://design.digital.go.jp/foundations/spacing/",
"https://design.digital.go.jp/foundations/layout/",
"https://design.digital.go.jp/foundations/elevation/",
"https://design.digital.go.jp/components/button/",
"https://design.digital.go.jp/components/",
"https://raw.githubusercontent.com/digital-go-jp/design-tokens/main/figma/tokens.json"
],
"extractedAt": "2026-05-18",
"notes": [
"直接証拠: 全カラー値は digital-go-jp/design-tokens リポジトリの figma/tokens.json から直接抽出。",
"直接証拠: ロゴ色 (#252020) は /themes/custom/gov_theme_da_2023/logo.svg の fill 値から直接抽出。",
"直接証拠: ボタンサイズ (Large 136x56 / Medium 96x48 / Small 80x36 / X-Small 72x28) はコンポーネントドキュメントから直接抽出。",
"推論: セマンティックカラー (primary, link) は Figma で定義されているが CSS 非公開のため、ボタンドキュメントと公式サイト観察から Blue-700 を primary と推定。",
"推論: エレベーション (shadow) の具体的な CSS 値は非公開、8 段階の構造のみ文書化。",
"重要: フォントウェイトは 400 (Normal) と 700 (Bold) のみ、500 / 600 を使用しない設計判断。",
"重要: ボタンには Oneline スタイル (line-height: 100%) を使用、本文 (Standard) とは別系統。",
"重要: テキストには Gray-536 (#767676) より薄いグレーを使用しない (4.5:1 vs White の最小値)。",
"重要: 非テキスト要素には Gray-420 (#949494) より薄いグレーを使用しない (3:1 vs White の最小値)。",
"重要: visited リンク色は青との混同回避のため Purple より Magenta を推奨。"
],
"colors": {
"groups": [
{
"label": "Primary Action (推定)",
"tokens": [
{
"name": "Primary",
"value": "#3460fb",
"token": "--color-primary",
"role": "主要ボタン背景・フォーカスリング・リンク (Blue-700)。Figma セマンティックトークンで定義、CSS 非公開のため推定"
},
{
"name": "Primary Hover",
"value": "#264af4",
"token": "--color-primary-hover",
"role": "プライマリ要素のホバー (Blue-800)"
},
{
"name": "Primary Active",
"value": "#0031d8",
"token": "--color-primary-active",
"role": "プライマリ要素のアクティブ (Blue-900)"
}
]
},
{
"label": "Blue Scale (13 Levels)",
"tokens": [
{
"name": "Blue-100",
"value": "#e8f1fe",
"token": "--color-blue-100",
"role": "最薄ブルー (背景・薄帯)"
},
{
"name": "Blue-200",
"value": "#d9e6ff",
"token": "--color-blue-200",
"role": "ライトブルー (情報バナー背景候補)"
},
{
"name": "Blue-300",
"value": "#c5d7fb",
"token": "--color-blue-300",
"role": "ライトブルー"
},
{
"name": "Blue-400",
"value": "#9db7f9",
"token": "--color-blue-400",
"role": "ミッドブルー (淡)"
},
{
"name": "Blue-500",
"value": "#7096f8",
"token": "--color-blue-500",
"role": "ミッドブルー"
},
{
"name": "Blue-600",
"value": "#4979f5",
"token": "--color-blue-600",
"role": "ミッドブルー (濃)"
},
{
"name": "Blue-700",
"value": "#3460fb",
"token": "--color-blue-700",
"role": "Primary 推定・主要インタラクション色"
},
{
"name": "Blue-800",
"value": "#264af4",
"token": "--color-blue-800",
"role": "ホバー状態"
},
{
"name": "Blue-900",
"value": "#0031d8",
"token": "--color-blue-900",
"role": "アクティブ状態"
},
{
"name": "Blue-1000",
"value": "#0017c1",
"token": "--color-blue-1000",
"role": "ダークブルー"
},
{
"name": "Blue-1100",
"value": "#00118f",
"token": "--color-blue-1100",
"role": "ダークブルー (深)"
},
{
"name": "Blue-1200",
"value": "#000071",
"token": "--color-blue-1200",
"role": "ダークブルー (最深手前)"
},
{
"name": "Blue-1300",
"value": "#000060",
"token": "--color-blue-1300",
"role": "最深ブルー"
}
]
},
{
"label": "Neutrals (SolidGray 12 Levels)",
"tokens": [
{
"name": "White",
"value": "#ffffff",
"token": "--color-white",
"role": "メイン背景・カード背景"
},
{
"name": "Black",
"value": "#000000",
"token": "--color-black",
"role": "純黒 (Info Banner 等の限定使用)"
},
{
"name": "Gray-50",
"value": "#f2f2f2",
"token": "--color-gray-50",
"role": "ページ背景・薄サーフェス"
},
{
"name": "Gray-100",
"value": "#e6e6e6",
"token": "--color-gray-100",
"role": "薄ボーダー・区切り線"
},
{
"name": "Gray-200",
"value": "#cccccc",
"token": "--color-gray-200",
"role": "標準ボーダー"
},
{
"name": "Gray-300",
"value": "#b3b3b3",
"token": "--color-gray-300",
"role": "中ボーダー"
},
{
"name": "Gray-400",
"value": "#999999",
"token": "--color-gray-400",
"role": "ミュート要素"
},
{
"name": "Gray-420",
"value": "#949494",
"token": "--color-gray-420",
"role": "非テキスト最小値 (3:1 vs White)"
},
{
"name": "Gray-500",
"value": "#7f7f7f",
"token": "--color-gray-500",
"role": "ミッドグレー"
},
{
"name": "Gray-536",
"value": "#767676",
"token": "--color-gray-536",
"role": "テキスト最小値 (4.5:1 vs White) — これより薄いグレーをテキストに使わない"
},
{
"name": "Gray-600",
"value": "#666666",
"token": "--color-gray-600",
"role": "セカンダリテキスト (3:1 vs Black)"
},
{
"name": "Gray-700",
"value": "#4d4d4d",
"token": "--color-gray-700",
"role": "強テキスト"
},
{
"name": "Gray-800",
"value": "#333333",
"token": "--color-gray-800",
"role": "ダークテキスト"
},
{
"name": "Gray-900",
"value": "#1a1a1a",
"token": "--color-gray-900",
"role": "本文テキスト推奨色 (最濃)"
}
]
},
{
"label": "Semantic Status",
"tokens": [
{
"name": "Success",
"value": "#259d63",
"token": "--color-success",
"role": "成功状態 (Green-600)・通知バナー"
},
{
"name": "Success Dark",
"value": "#197a4b",
"token": "--color-success-dark",
"role": "成功要素のホバー/アクティブ (Green-800)"
},
{
"name": "Error",
"value": "#ec0000",
"token": "--color-error",
"role": "エラー状態 (Red-800)・通知バナー・入力エラー"
},
{
"name": "Error Dark",
"value": "#ce0000",
"token": "--color-error-dark",
"role": "エラー要素のホバー (Red-900)"
},
{
"name": "Warning Yellow",
"value": "#b78f00",
"token": "--color-warning-yellow",
"role": "警告 (Yellow-700)・通知バナー"
},
{
"name": "Warning Yellow Dark",
"value": "#927200",
"token": "--color-warning-yellow-dark",
"role": "警告イエローのホバー (Yellow-900)"
},
{
"name": "Warning Orange",
"value": "#fb5b01",
"token": "--color-warning-orange",
"role": "警告 (Orange-600)・通知バナー (より強い警告)"
},
{
"name": "Warning Orange Dark",
"value": "#c74700",
"token": "--color-warning-orange-dark",
"role": "警告オレンジのホバー (Orange-800)"
}
]
},
{
"label": "Logo",
"tokens": [
{
"name": "Logo Black",
"value": "#252020",
"token": "--color-logo",
"role": "ロゴ標準色 (logo.svg の fill 値から直接抽出) — チャコールブラック"
}
]
}
]
},
"typography": {
"fonts": [
{
"family": "Noto Sans JP",
"stack": "'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif",
"weights": [
400,
700
],
"role": "primary",
"notes": "本文・見出し・UI 全般。SIL Open Font License 1.1。日英混在コンテンツに最適化、中間ウェイト (500/600) は使用しない設計判断"
},
{
"family": "Noto Sans Mono",
"stack": "'Noto Sans Mono', monospace",
"weights": [
400
],
"role": "mono",
"notes": "コードブロック・等幅表示用 (14px〜24px の 6 スタイル)"
}
],
"scale": [
{
"role": "display (Hero)",
"size": "48px-64px",
"weight": 700,
"lineHeight": 1.4,
"note": "ヒーロー・大見出し (Display-sm 48 / Display-md 57 / Display-lg 64 の 6 スタイル)"
},
{
"role": "h1",
"size": "36px",
"weight": 700,
"lineHeight": 1.5,
"note": "ページタイトル (Standard カテゴリ・xl3 トークン)"
},
{
"role": "h2",
"size": "32px",
"weight": 700,
"lineHeight": 1.5,
"note": "メジャーセクション見出し (xl2 トークン)"
},
{
"role": "h3",
"size": "24px",
"weight": 700,
"lineHeight": 1.5,
"note": "セクション見出し (lg トークン)"
},
{
"role": "body-large",
"size": "18px",
"weight": 400,
"lineHeight": 1.75,
"note": "強調本文・リード文 (md トークン)"
},
{
"role": "body",
"size": "16px",
"weight": 400,
"lineHeight": 1.75,
"note": "本文ベースライン (sm トークン)。line-height 175% は日本語可読性のため広め"
},
{
"role": "body-small (Dense)",
"size": "14px",
"weight": 400,
"lineHeight": 1.5,
"note": "データ集約 UI・補助テキスト (xs トークン)"
},
{
"role": "label (Oneline)",
"size": "16px",
"weight": 400,
"lineHeight": 1,
"note": "UI ラベル・ボタンテキスト専用 (line-height: 100% が特徴)"
},
{
"role": "mono",
"size": "14px-24px",
"weight": 400,
"lineHeight": 1.5,
"note": "コード表示 (Noto Sans Mono)"
}
],
"japanese": {
"fontStack": "'Noto Sans JP', -apple-system, BlinkMacSystemFont, sans-serif",
"lineHeight": 1.75,
"letterSpacing": "0",
"openType": {
"palt": false,
"kern": true
},
"kinsoku": {
"wordBreak": "keep-all",
"lineBreak": "strict"
},
"notes": [
"Noto Sans JP の単一スタック (他フォントへの切り替えは Don't 違反)",
"ウェイトは 400 / 700 のみ運用、500 / 600 は使用しない",
"本文 line-height は 1.75 (175%) を採用、日本語の可読性を優先",
"ボタン・UI ラベルには Oneline (line-height: 1.0) を使う"
]
}
},
"spacing": {
"baseUnit": "8px",
"tokens": [
{
"name": "1x",
"value": "8px",
"role": "コンポーネント内最小パディング"
},
{
"name": "2x",
"value": "16px",
"role": "標準的な要素間隔"
},
{
"name": "3x",
"value": "24px",
"role": "セクション内グループ間隔"
},
{
"name": "4x",
"value": "32px",
"role": "中間スペース・ガター幅 (本文 16px × 2)"
},
{
"name": "5x",
"value": "40px",
"role": "中余白"
},
{
"name": "6x",
"value": "48px",
"role": "セクション間"
},
{
"name": "8x",
"value": "64px",
"role": "大セクション区切り"
}
]
},
"breakpoints": {
"mobileTablet": {
"value": "< 768px",
"role": "モバイル・タブレット (12 カラムグリッドのコンパクト版)"
},
"desktop": {
"value": "≥ 768px",
"role": "デスクトップ (12 カラムグリッド、左ナビ固定幅 + メインの 2 ペインが標準)"
}
},
"radius": {
"sm": "4px",
"md": "6px",
"lg": "8px",
"xl": "12px",
"2xl": "16px",
"3xl": "24px",
"4xl": "32px",
"full": "9999px"
},
"components": [
{
"type": "button",
"name": "Filled Button (Primary)",
"description": "プライマリブルー背景のメイン CTA。重要度高。最小タッチターゲット 44px、ボタンテキストは Oneline スタイル (line-height: 100%)",
"variants": [
{
"label": "Large",
"props": {
"background": "#3460fb",
"color": "#ffffff",
"borderRadius": "8px",
"minWidth": "136px",
"height": "56px",
"fontSize": "16px",
"fontWeight": "700",
"lineHeight": "1.0"
}
},
{
"label": "Medium",
"props": {
"background": "#3460fb",
"color": "#ffffff",
"borderRadius": "8px",
"minWidth": "96px",
"height": "48px",
"fontSize": "16px",
"fontWeight": "700",
"lineHeight": "1.0"
}
},
{
"label": "Small",
"props": {
"background": "#3460fb",
"color": "#ffffff",
"borderRadius": "8px",
"minWidth": "80px",
"height": "44px",
"fontSize": "16px",
"fontWeight": "700",
"lineHeight": "1.0",
"note": "高さ 36px だが 44px タッチターゲット確保のためパディングで補完"
}
},
{
"label": "Hover",
"props": {
"background": "#264af4",
"color": "#ffffff",
"borderRadius": "8px"
}
},
{
"label": "Active",
"props": {
"background": "#0031d8",
"color": "#ffffff",
"borderRadius": "8px"
}
}
]
},
{
"type": "button",
"name": "Outline Button (Secondary)",
"description": "白背景 + ブルー 1px 枠のセカンダリボタン。重要度中",
"variants": [
{
"label": "Default",
"props": {
"background": "#ffffff",
"color": "#3460fb",
"border": "1px solid #3460fb",
"borderRadius": "8px",
"fontSize": "16px",
"fontWeight": "700",
"lineHeight": "1.0"
}
},
{
"label": "Hover",
"props": {
"background": "#e8f1fe",
"color": "#264af4",
"border": "1px solid #264af4",
"borderRadius": "8px"
}
}
]
},
{
"type": "button",
"name": "Text Button (Tertiary)",
"description": "透明背景 + 下線のテキストボタン。重要度低",
"variants": [
{
"label": "Default",
"props": {
"background": "transparent",
"color": "#3460fb",
"textDecoration": "underline",
"fontSize": "16px",
"fontWeight": "700",
"lineHeight": "1.0"
}
},
{
"label": "Hover",
"props": {
"background": "transparent",
"color": "#264af4",
"textDecoration": "underline"
}
}
]
},
{
"type": "card",
"name": "Card",
"description": "単一トピックをグルーピングする白背景コンテナ。サムネイル + 見出し + 本文 + リンク/アクションで構成",
"variants": [
{
"label": "Default",
"props": {
"background": "#ffffff",
"color": "#1a1a1a",
"borderRadius": "12px",
"elevation": "Level 1",
"padding": "24px"
}
},
{
"label": "Hover",
"props": {
"background": "#ffffff",
"color": "#1a1a1a",
"borderRadius": "12px",
"elevation": "Level 2"
}
}
]
},
{
"type": "input",
"name": "Text Input",
"description": "標準テキスト入力。フォーカスでブルーリング、エラーで赤ボーダー",
"variants": [
{
"label": "Default",
"props": {
"background": "#ffffff",
"color": "#1a1a1a",
"border": "1px solid #cccccc",
"borderRadius": "8px",
"padding": "12px 16px",
"fontSize": "16px"
}
},
{
"label": "Focus",
"props": {
"background": "#ffffff",
"border": "2px solid #3460fb",
"borderRadius": "8px",
"outline": "none"
}
},
{
"label": "Error",
"props": {
"background": "#ffffff",
"border": "1px solid #ec0000",
"borderRadius": "8px",
"errorTextColor": "#ec0000"
}
},
{
"label": "Disabled",
"props": {
"background": "#f2f2f2",
"color": "#949494",
"border": "1px solid #cccccc",
"borderRadius": "8px"
}
}
]
},
{
"type": "banner",
"name": "Notification Banner",
"description": "ステータス通知バナー。Standard (角丸全体) / Color Chip (左側に太いアクセントボーダー) の 2 スタイル。アイコン + テキストで色覚多様性に配慮",
"variants": [
{
"label": "Success",
"props": {
"background": "#259d63",
"color": "#ffffff",
"borderRadius": "8px",
"icon": "✓"
}
},
{
"label": "Error",
"props": {
"background": "#ec0000",
"color": "#ffffff",
"borderRadius": "8px",
"icon": "×"
}
},
{
"label": "Warning Yellow",
"props": {
"background": "#b78f00",
"color": "#ffffff",
"borderRadius": "8px",
"icon": "!"
}
},
{
"label": "Warning Orange",
"props": {
"background": "#fb5b01",
"color": "#ffffff",
"borderRadius": "8px",
"icon": "!"
}
},
{
"label": "Info Blue",
"props": {
"background": "#3460fb",
"color": "#ffffff",
"borderRadius": "8px",
"icon": "ℹ"
}
},
{
"label": "Info Black",
"props": {
"background": "#000000",
"color": "#ffffff",
"borderRadius": "8px",
"icon": "ℹ"
}
}
]
},
{
"type": "chip",
"name": "Chip / Tag",
"description": "ピル形状のラベル要素。状態表示・カテゴリ分類用",
"variants": [
{
"label": "Default",
"props": {
"background": "#e8f1fe",
"color": "#3460fb",
"borderRadius": "9999px",
"padding": "4px 12px",
"fontSize": "14px",
"fontWeight": "400"
}
}
]
},
{
"type": "focus",
"name": "Focus Ring",
"description": "フォーカス状態の視覚インジケーター。すべてのインタラクティブ要素に必須",
"variants": [
{
"label": "Default",
"props": {
"outline": "2px solid #3460fb",
"outlineOffset": "2px"
}
}
]
}
],
"guidelines": {
"do": [
"Noto Sans JP のみを使用する — 他フォントへの切り替えは不可",
"ブルーを主要インタラクション色として一貫して使用する (Blue-700: #3460fb)",
"本文テキストには Gray-900 (#1a1a1a) を基本にする",
"テキストの最低コントラスト比 4.5:1 を維持する (WCAG 2.2 AA)",
"非テキスト要素の最低コントラスト比 3:1 を維持する",
"フォーカスインジケーターを必ず視覚的に明示する",
"ボタンの最小タッチターゲットを 44px × 44px に保つ",
"8px グリッドでスペースを定義する",
"カラーとアイコン/ラベル/パターンの両方で情報を伝える (色覚多様性対応)",
"ボタンはページ内の重要度順に Filled → Outline → Text と使い分ける",
"ボタンには Oneline スタイル (line-height: 100%) を使う"
],
"dont": [
"Gray-420 (#949494) より薄いグレーをテキストに使用しない",
"Gray-536 (#767676) より薄いグレーをテキストコントラストとして使用しない",
"プライマリ (Filled) ボタンを複数並べて重要度を希釈しない",
"ロゴを変形・再彩色・トリミングしない (#252020 の単色のみ)",
"フォントウェイト 500 / 600 を使用しない (400 と 700 のみ)",
"リンクの visited 色 (Magenta/Purple) をナビゲーション要素に転用しない",
"カラーのみで情報を伝えない (アイコン・ラベル・パターンを併用する)",
"プライマリ青をテキストの大段落色として使わない (リンクとの識別不可)"
]
}
}
